import pandas as pd
import numpy as np
import matplotlib.pyplot as plt

df = pd.read_csv("datasets/House_Property_Sales_Time_Series.csv", usecols=["datesold", "price"],parse_dates=["datesold"])
# Group sales by month
yearly_grouped = df.groupby(pd.Grouper(key='datesold', freq='YE')).sum()
print(yearly_grouped)
# Map to 0-9 values
original_min = yearly_grouped['price'].min()
original_max = yearly_grouped['price'].max()
target_min = 0
target_max = 9
mapped = (((yearly_grouped['price'] - original_min) / (original_max - original_min)) * (target_max - target_min) + target_min).astype(int)
print(mapped.values)

                 price
datesold
2007-12-31    76789450
2008-12-31   315547250
2009-12-31   707427239
2010-12-31   870123280
2011-12-31   925445775
2012-12-31  1026547544
2013-12-31  1172689133
2014-12-31  1696767719
2015-12-31  2284017698
2016-12-31  2482304198
2017-12-31  3051009584
2018-12-31  2548984623
2019-12-31   878345143
[0 0 1 2 2 2 3 4 6 7 9 7 2]

# Display basic chart
plt.plot(mapped.index, mapped.values,'o')
plt.xlabel('Years')
plt.ylabel('Sales')
plt.show()

# Play a different sound when the market grows, is stable or decline

import numpy as np
from IPython.display import Audio, display

digits = mapped.values
rate = 44100
def custom_tone(digit,duration,rate,amplitude):
    frequencies = {
        '1':(697,1209),'2':(697,2222),'3':(697,1477),
        '4':(770,1209),'5':(770,3333),'6':(770,1477),
        '7':(852,1209),'8':(852,6666),'9':(852,1477),
        '*':(941,1209),'0':(941,1336),'#':(941,1477)}
    low,high = frequencies[digit]
    t = np.linspace(0,duration,int(rate*duration),endpoint=False)
    tone = amplitude*(np.sin(2*np.pi*low*t)+np.sin(2*np.pi*high*t))
    return tone
def generate_tone(digits,duration=0.3,silence=0.3,rate=44100,amplitude=0.5):
    data = np.array([])
    previous = 0
    for digit in digits:
        if (digit == previous):
            tone = custom_tone('5',duration,rate,amplitude)
        else:
            if (digit > previous):
                tone = custom_tone('8',duration,rate,amplitude)
            else:
                tone = custom_tone('2',duration,rate,amplitude)
        previous = digit
        silence = np.zeros(int(rate*duration))
        data = np.concatenate((data,tone,silence))
    return data
data = generate_tone(digits,rate=rate)
data = data/np.max(np.abs(data))*(2**15-1)
data = data.astype(np.int16)
display(Audio(data,rate=rate))

import pandas as pd
import numpy as np
import seaborn as sns
import matplotlib.pyplot as plt

df = pd.read_csv("datasets/sensor-fault-detection.csv", sep=';', parse_dates=["Timestamp"])
df.head()

df.shape

(62629, 3)

print(df['SensorId'].unique())
df.describe()

[1]

plt.figure(figsize=(10, 6))
plt.plot(df['Timestamp'], df['Value'], '.')
plt.title('Sensor Data')
plt.xlabel('Time')
plt.ylabel('Measurement')
plt.grid(True)
plt.xticks(rotation=45)
plt.tight_layout()

# we have outliers and some missing data!
# 8 outliers detected - all showing the exact same suspicious value of 149.6° (likely a sensor fault), occurring in March 2017.

# Check for missing values
print(f"\nMissing values:")
print(df.isnull().sum())

# Check for duplicates
duplicates = df.duplicated().sum()
print(f"\nDuplicate rows: {duplicates}")
if duplicates > 0:
    df = df.drop_duplicates()
    print(f"Removed {duplicates} duplicate rows")

# Sort by Timestamp and SensorId
df = df.sort_values('Timestamp').reset_index(drop=True)

# Remove any rows with missing values (if any)
df = df.dropna()
# Calculate Q1, Q3, and IQR
Q1 = df['Value'].quantile(0.25)
Q3 = df['Value'].quantile(0.75)
IQR = Q3 - Q1

# Define lower and upper bounds for outliers
lower_bound = Q1 - 1.5 * IQR
upper_bound = Q3 + 1.5 * IQR
print('Lower: ', lower_bound, ' Upper: ', upper_bound)

# Remove outliers
df = df[(df['Value'] >= lower_bound) & (df['Value'] <= upper_bound)]

plt.figure(figsize=(16, 6) )
plt.plot(df['Timestamp'], df['Value'], '.')
plt.title('Sensor Data - without outliers')
plt.xlabel('Time')
plt.ylabel('Measurement')
plt.grid(True)
plt.xticks(rotation=45)
plt.tight_layout()

# now we can see there are gaps with no readings !

# Define the start and end dates for filtering
start_date = '2017-04-15'
end_date = '2017-05-15'

# Filter the DataFrame
filtered_df = df.loc[(df['Timestamp'] >= start_date) & (df['Timestamp'] <= end_date)]
plt.figure(figsize=(16, 6) )
plt.plot(filtered_df['Timestamp'], filtered_df['Value'], '.')
plt.title('Sensor Data - one month zoom')
plt.xlabel('Time')
plt.ylabel('Measurement')
plt.grid(True)
plt.xticks(rotation=45)
plt.tight_layout()

# Define the start and end dates for filtering
start_date = '2017-04-29'
end_date = '2017-04-30'

# Filter the DataFrame
filtered_df = df.loc[(df['Timestamp'] >= start_date) & (df['Timestamp'] <= end_date)]
plt.figure(figsize=(16, 6) )
plt.plot(filtered_df['Timestamp'], filtered_df['Value'], '.')
plt.title('Sensor Data - one day zoom')
plt.xlabel('Time')
plt.ylabel('Measurement')
plt.grid(True)
plt.xticks(rotation=45)
plt.tight_layout()

Missing values:
Timestamp    0
SensorId     0
Value        0
dtype: int64

Duplicate rows: 0
Lower:  12.835803025000002  Upper:  36.362971305

	Timestamp	SensorId	Value
0	2017-03-01 23:20:00+03:00	1	18.479807
1	2017-03-02 04:00:00+03:00	1	19.539112
2	2017-03-23 06:25:00+03:00	1	19.250198
3	2017-03-23 19:35:00+03:00	1	18.961285
4	2017-04-04 15:10:00+03:00	1	25.321623

	SensorId	Value
count	62629.0	62629.000000
mean	1.0	24.203861
std	0.0	5.411599
min	1.0	6.886155
25%	1.0	21.369419
50%	1.0	24.550188
75%	1.0	27.443794
max	1.0	149.601822

Week 7: transforms¶

Experiment 1 - "listen" to the house market¶

Experiment 2 - Improve raw sensor data¶
