6.Density Estimation

Prompt(ChatGPT)
What is density estimation in Data science?

Answer
the process of estimating the underlying probability distribution that generated a set of observed data points

Why density estimation is important
Density estimation is used to:

• Understand the shape of data (normal, skewed, multimodal, etc.)
• Identify outliers or anomalies
• Compare distributions between groups
• Generate synthetic data
• Serve as a basis for clustering, classification, and simulation

Assignment

• Fit a probability distribution to your data

Understanding Class sample code

Prompt(CharGPT)
I would like you to explain this Voronoi tesselation code. Please add step numbers and write brief comments in the code explaining each step.　　

Answer
The answer is below

# Voronoi tesselation
import matplotlib.pyplot as plt
from scipy.spatial import Voronoi, voronoi_plot_2d
import numpy as np
import time

#
# Step 1: Set k-means parameters
#　　　K-means の設定
npts = 1000
nclusters = 3
nsteps = 10
xs = [0, 5, 10]   # x-centers for generating data clusters
ys = [0, 10, 5]   # y-centers for generating data clusters
np.random.seed(0)

#
# Step 2: Generate random data around specified cluster centers
#　　　3つの中心をもとにランダムなデータを生成
x = np.array([])
y = np.array([])
for i in range(len(xs)):
    # Generate Gaussian-distributed points for each cluster center
    x = np.append(x, np.random.normal(loc=xs[i], scale=1, size=npts))
    y = np.append(y, np.random.normal(loc=ys[i], scale=1, size=npts))

#
# Step 3: Choose initial cluster center points randomly
#　　　初期クラスタ中心（セントロイド）をランダムに選ぶ
indices = np.random.uniform(low=0, high=len(x), size=nclusters).astype(int)
mux = x[indices]   # initial x-centroids
muy = y[indices]   # initial y-centroids

#
# Step 4: Plot initial points and Voronoi regions
#　　　初期状態のクラスタ中心と Voronoi 図を描画
fig, ax = plt.subplots()
plt.plot(x, y, '.')
vor = Voronoi(np.stack((mux, muy), axis=1))
voronoi_plot_2d(vor, ax=ax, show_points=True, show_vertices=False, point_size=20)
plt.autoscale()
plt.title('before k-means iterations')
plt.show()

#
# Step 5: Perform k-means iterations
#　　　　K-means の反復処理（nsteps 回）
for i in range(nsteps):

    #
    # Step 5-1: Compute distance from each data point to each centroid
    #　　　　すべてのデータとセントロイドの距離を計算
    xm = np.outer(x, np.ones(len(mux)))
    ym = np.outer(y, np.ones(len(muy)))
    muxm = np.outer(np.ones(len(x)), mux)
    muym = np.outer(np.ones(len(x)), muy)
    distances = np.sqrt((xm - muxm)**2 + (ym - muym)**2)

    # Step 5-2: Assign each data point to the closest centroid
    #   最も近いセントロイドを割り当てる
    mins = np.argmin(distances, axis=1)

    #
    # Step 5-3: Update centroids based on the assigned points
    #   セントロイドを更新
    for i in range(len(mux)):
        index = np.where(mins == i)
        mux[i] = np.sum(x[index]) / len(index[0])
        muy[i] = np.sum(y[index]) / len(index[0])

#
# Step 6: Plot results after k-means iterations
#   K-means 終了後の結果をプロット
fig, ax = plt.subplots()
plt.plot(x, y, '.')
vor = Voronoi(np.stack((mux, muy), axis=1))
voronoi_plot_2d(vor, ax=ax, show_points=True, show_vertices=False, point_size=20)
plt.autoscale()
plt.title('after k-means iteration')
plt.show()

They are the steps of the class code

Step 1: Set k-means parameters
Step 2: Generate random data around specified cluster centers
Step 3: Choose initial cluster center points randomly
Step 4: Plot initial points and Voronoi regions
Step 5: Perform k-means iterations
Step 5-1: Compute distance from each data point to each centroid
Step 5-2: Assign each data point to the closest centroid
Step 5-3: Update centroids based on the assigned points
Step 6: Plot results after k-means iterations

When analyzing real-world data using k-means and Voronoi diagrams, the following steps are used.

Step 1: Load real data
-Load your actual dataset from CSV, database, sensors, etc.
Step 2: Preprocess / normalize data (optional)
-Clean missing values and scale features if necessary.
Step 3: Initialize centroids
Use random initialization or an algorithm such as k-means++.
Step 4: Run k-means iteration
Perform iterative updates to compute cluster centroids.
Step 5: Apply Voronoi to the computed centroids
-Generate a Voronoi diagram using only the final k-means cluster centers.
Step 6: Visualize assignment + Voronoi diagram
-Plot the clustered points and overlay the Voronoi regions.

I asked to ChatGPT to generate dummy data and save as dummy_data.csv

Pronpt(ChatGPT)
Generate a realistic clustered dummy dataset in CSV format. Create four clusters with different centers and different standard deviations. Each cluster should have 300 points, and the output should contain only two columns: x and y. After generating the data, save it as a CSV file and provide a download link.

Answer

• day6_dummy_data.csv
• day6_realistic_dummy_data.csv

# Step 1: Load real data
import numpy as np

#data = np.loadtxt("data/day6_dummy_data.csv", delimiter=",", skiprows=1)
data = np.loadtxt("data/day6_realistic_dummy_data.csv", delimiter=",", skiprows=1)

x = data[:, 0]
y = data[:, 1]

# Step 2: Preprocess / Clean / Normalize
mask = ~np.isnan(x) & ~np.isnan(y)
x = x[mask]
y = y[mask]

# Step 3: Initialize centroids (k-means++)
from sklearn.cluster import KMeans

k = 4
model = KMeans(n_clusters=k, init="k-means++")
model.fit(np.stack([x, y], axis=1))

labels = model.labels_
centroids = model.cluster_centers_

# Step 5:Apply Voronoi
from scipy.spatial import Voronoi, voronoi_plot_2d
vor = Voronoi(centroids)

# 共通の描画範囲を計算
xmin, xmax = x.min(), x.max()
ymin, ymax = y.min(), y.max()

# Step 6-1: Plot only data points
import matplotlib.pyplot as plt

plt.figure(figsize=(8, 8))
plt.scatter(x, y, c=labels, s=5)
# クラスタ中心（大きなオレンジの点）
plt.scatter(centroids[:, 0], centroids[:, 1],
            color="orange", s=100, edgecolor="black")

plt.title("Step 6-1: Clustered Data Only")
plt.xlim(xmin, xmax)
plt.ylim(ymin, ymax)
plt.gca().set_aspect("equal", adjustable="box")
plt.show()

# Step 6-2: Plot data + Voronoi
fig2 = plt.figure(figsize=(8, 8))
ax2 = fig2.add_subplot(111)

ax2.scatter(x, y, c=labels, s=5)
ax2.scatter(centroids[:, 0], centroids[:, 1],
            color="orange", s=100, edgecolor="black")

# → axis を指定する
voronoi_plot_2d(vor, ax=ax2, show_points=True, show_vertices=False)

ax2.set_title("Step 6-2: k-means + Voronoi Diagram")
ax2.set_xlim(xmin, xmax)
ax2.set_ylim(ymin, ymax)
ax2.set_aspect("equal", adjustable="box")
plt.show()

Fit a probability distribution to real data

Inside Airbnb is a mission driven project that provides data and advocacy about Airbnb's impact on residential communities.

I have chosen

• Tokyo, Kantō, Japan
  • listings.csv
  • Summary information and metrics for listings in Tokyo (good for visualisations).
    This dataset includes lots of information. To fit a probability distribution, I delete all data except latitude and longitude.

# Step 1: Load real data
import numpy as np

#data = np.loadtxt("data/day6_tokyo.csv", delimiter=",", skiprows=1)
data = np.loadtxt("data/day6_tokyo.csv", delimiter=",", skiprows=1)

x = data[:, 1] #longitude → East-West(東西方向) → x Axis
y = data[:, 0] #latitude → North-South(南北方向) → y Axis

# Step 2: Preprocess / Clean / Normalize
mask = ~np.isnan(x) & ~np.isnan(y)
x = x[mask]
y = y[mask]

# Step 3: Initialize centroids (k-means++)
from sklearn.cluster import KMeans

k = 6
model = KMeans(n_clusters=k, init="k-means++")
model.fit(np.stack([x, y], axis=1))

labels = model.labels_
centroids = model.cluster_centers_

# Step 5:Apply Voronoi
from scipy.spatial import Voronoi, voronoi_plot_2d
vor = Voronoi(centroids)

# Calculate a common plotting range
# 共通の描画範囲を計算
xmin, xmax = x.min(), x.max()
ymin, ymax = y.min(), y.max()

# Step 6-1: Plot only data points
import matplotlib.pyplot as plt

plt.figure(figsize=(8, 8))
plt.scatter(x, y, c=labels, s=5)
# クラスタ中心（大きなオレンジの点）
plt.scatter(centroids[:, 0], centroids[:, 1],
            color="orange", s=100, edgecolor="black")

plt.title("Step 6-1: Clustered Data Only")
plt.xlim(xmin, xmax)
plt.ylim(ymin, ymax)
plt.gca().set_aspect("equal", adjustable="box")
plt.show()

# Step 6-2: Plot data + Voronoi
fig2 = plt.figure(figsize=(8, 8))
ax2 = fig2.add_subplot(111)

ax2.scatter(x, y, c=labels, s=5)
ax2.scatter(centroids[:, 0], centroids[:, 1],
            color="orange", s=100, edgecolor="black")

# → axis を指定する
voronoi_plot_2d(vor, ax=ax2, show_points=True, show_vertices=False)

ax2.set_title("Step 6-2: k-means + Voronoi Diagram")
ax2.set_xlim(xmin, xmax)
ax2.set_ylim(ymin, ymax)
ax2.set_aspect("equal", adjustable="box")
plt.show()

This is the map of Tokyo. The blue area is Tokyo’s 23 wards, the most densely populated part of Tokyo.
